H1: YGM Series H Frame Hydraulic Press Machine – Efficient and Precise Solution for H Type Hydraulic Forming

In industries such as metal processing, aerospace, and automotive components, h frame hydraulic press machines are core equipment for complex part manufacturing due to their stable pressure output and high-precision forming capabilities. The YGM series of closed hydraulic press machines combines innovative structural design, intelligent control systems, and high-efficiency hydraulic technology to deliver a versatile solution integrating high rigidity, precision, and flexibility for applications like drawing, bending, and pressing.

H2: Monolithic Frame Structure Redefines Hydraulic Press Rigidity Standards

H3: Advanced Welding Technology for High-Strength Body

The YGM series features a monolithic h frame structure, with the body and slider constructed from high-strength low-alloy steel plates using advanced sheet metal forming and welding techniques. This increases material tensile strength by 20% and achieves an overall rigidity of 1/5000, effectively reducing stamping vibration (amplitude ≤0.08mm). The stable support provided to molds eliminates workpiece dimensional deviations caused by frame deformation, making it ideal for precision aerospace component manufacturing.

H3: Integrated Design for Easy Transportation and Installation

The pump station and electrical cabinet are integrated into the h type hydraulic press machine body, eliminating the need for disassembly during transportation. This reduces installation time by 40% compared to traditional split-type hydraulic presses, as the fully pre-commissioned equipment only requires power and hydraulic connections to start operation, significantly lowering deployment costs.

H2: Precision Guidance and Lubrication for Forming Accuracy

H3: Quadruple Octagonal Guides Enhance Eccentric Load Resistance

Equipped with quadruple octagonal linear guides, the contact area is increased by 60% compared to traditional four-sided guides, achieving a guidance accuracy of ±0.02mm/m and 50% stronger eccentric load resistance. Even under 30% eccentric load, the slider maintains stable movement. The centralized automatic lubrication system (customizable lubrication intervals) reduces guide wear by 30% and extends maintenance cycles to 6 months, ensuring long-term precision.

H3: Large-Diameter Fluid Valve Boosts Production Efficiency

A custom large-diameter fluid valve (35% higher flow rate) enables rapid slider descent and return (idle speed up to 200mm/s), increasing efficiency by 25% compared to conventional hydraulic press machines. In automotive panel drawing processes, cycle time per station is reduced to 8 seconds, significantly enhancing production capacity and saving over 30% annual time costs.

H2: Intelligent Control and Hydraulic System for Flexible Production

H3: Omron PLC Control Enables Multi-Process Quick Switching

The Omron PLC intelligent control system allows users to customize parameters like pressure, speed, and stroke via HMI, supporting quick switching between 10+ processes (drawing, embossing, straightening) without modifying external circuits. Real-time status monitoring and fault diagnosis improve maintenance efficiency by 60%, making it ideal for multi-variety small-batch production.

H3: Cartridge Valve Integration for Reliable Low-Impact Operation

The hydraulic system uses cartridge valve integration technology, with a response time ≤0.1 seconds and pressure fluctuation ≤±1%, improving reliability by 40% over traditional 管式 valves. The shock-absorbing design reduces hydraulic impact by 50%, minimizing pipeline vibration and noise (≤85dB), and extending seal life by 20% for long-term stable operation.

H2: Patent-Enhanced Cylinders for Harsh Working Conditions

H3: Patent Material Improves Cylinder Reliability

Cylinder bodies use patented surface hardening technology (HRC55-60 hardness), and piston rods are coated with nano-ceramic layers, tripling wear resistance and increasing corrosion resistance by 40%. In harsh environments, cylinder leakage failure rates are reduced by 70%, making it suitable for processing titanium aerospace parts and marine stainless-steel components.

H3: Fully Adjustable Parameters for Diverse Processes

Slider pressure (50-5000 tons), speed (5-200mm/s), and stroke (200-1500mm) are infinitely adjustable via HMI. Standard pressure sensors (±0.5%FS accuracy) and displacement encoders (0.01mm resolution) enable real-time monitoring of pressure-displacement curves, meeting sensitive process requirements for precision pressing and die forging.

H3: Available for Upgrading to Servo Hydraulic Press

The YGM H frame hydraulic press can be upgraded to servo type press machine features:

1.       20%-50% energy is saved;

2.       Noise is lower than 75 db

3.       Temperature is raised lower than 22℃.

H2: Technical Specifications and Industry Applications

H3: Multi-Model Options for Different Capacity Needs

插入表格

H3: Typical Application Scenarios

• Automotive: Door inner panel drawing, engine bushing pressing, gearbox forming

• Aerospace: Titanium alloy rib forging, aluminum alloy panel straightening

• Home Appliances: Washing machine drum deep drawing, stainless steel sink forming

FAQ: Frequently Asked Questions

Q1: What are the core advantages of the YGM series h type hydraulic press machine?

A: Three key advantages: ① H frame hydraulic press machine structure with 20% higher rigidity and strong eccentric load resistance; ② Omron PLC control for full parameter customization enabling flexible production; ③ Cartridge valve system with high efficiency, long life, and 30% lower maintenance costs.

Q2: Is the machine suitable for high-precision pressing processes?

A: Yes, equipped with high-precision displacement encoders (0.01mm resolution) and pressure sensors (±0.5%FS accuracy), it supports dual control of pressure and displacement, meeting micron-level precision requirements for bearing pressing and motor stator positioning.

Q3: Does the centralized lubrication system require manual intervention?

A: The system supports automatic timed lubrication (default 30-minute interval) with oil level alarms. Only monthly lubricant level checks are needed, significantly reducing manual maintenance.

Q4: How is the hydraulic system oil temperature controlled?

A: A built-in cooler (optional heater) automatically regulates oil temperature between 35-55℃ via temperature sensors, ensuring stable viscosity and long-term efficient operation of the hydraulic press.

Q5: Can worktable dimensions be customized?

A: Yes, customization is available for worktable size, opening height, and other parameters to fit customer molds. A quick die change device is also optional to further improve efficiency.

YGM Series H Frame Hydraulic Press Machine – Redefining the Benchmark for H Type Hydraulic Press Precision and Efficiency!Contact us today for customized solutions: WhatsApp: +18317313453
